Modern Design Luxury Living 3 Bedroom Container Home with Bathroom

CE ISO Modern design luxury living 3 bedroom container house with toiletProduct Introduction1. The container house is made by steel frame structure, which adopts Hot-form galvanized steel.2. Structure is consists of three modular parts: roofing frame, corner column and floor frame.3. Each modular is manufactured at the

Featured Products

CE ISO Modern design luxury living 3 bedroom container house with toilet

Product Introduction
1. The container house is made by steel frame structure, which adopts Hot-form galvanized steel.
2. Structure is consists of three modular parts: roofing frame, corner column and floor frame.
3. Each modular is manufactured at the factory and assembled on construction site.
4. With one single container house as basic unit, it can be combined horizontally or vertically in different form like building blocks.
5. Flat pack container house can be stacked in three storeys with flexible in space layout and multiple function, and can be used in different application fields.

Modern Design Luxury Living 3 Bedroom Container House with Toilet

Product Advantages :
1.Flexible combination,modular house can be easily combined, time and labor saving.
2.Easy assembly. We provide install drawings and video.
3.Good insulation. It can suffer extreme climate.
4.Good looking and neat inside.
5.Good resistance for water,wind and earthquake.

6.long lifespan 15-20 years
7.Comfortable for living and working.
Modern Design Luxury Living 3 Bedroom Container House with Toilet


ItemMaterials
Dimension6000*2440*2920mm
Weight18000
STEEL FRAME1.Material: Q235 galvanized steel; thickness, 2.5~4.0mm
2.Support:C100x40x2.0 or C80x40x1.2 purlin
3.Connection: high strength bolt M12*40
4.Surface working: sand blasting, epoxy basic painting 55μm, final vinyl acrylic painting 55μm thick
Top and bottom gray (rust-proof primer, gray finish)
Column: 210x150x2550mm 2.5mm--4pcs
Wall   Wall Panel: 75mm thickness glass fiber sandwich panel , 0.5mm colored steel
ROOFOutside Steel: 0.5mm steel sheet
Keel: C80x40x20x2.0 or C80x40x1.2 steel purline
Insulation Layer: 100mm thickness fiber glass(16kg/m3), Fire-proof level: A
Ceiling: 0.5mm colored-steel +Ceiling aluminum edge
Rainspout:Water flow to the four corner
 FLOORMaterial: Q235 galvanized steel; thickness, 2.5~4.0mm
Keel: C100x50x2.0 or C100x50x1.5 square tube,galvanized steel

Insulation Layer: 100mm thickness fiber glass
Cement floor: 18mm thickness cement particle board
Surface: PVC Floor leather (thickness 2.0mm)
Doors0.5mm double-sided steel security door  with high quality press lock
Size: 970x2070mm  840x2070mm
WindowsWindows : Plastic steel hollow glass sliding window (usually 2pcs) with screen and security net,
Size: 930x1200mm
Electricity SystemDouble tube fluorescent light (usually 2 pcs)
Electrical wire, 2.5mm2 for lighting system,  4mm2 for AC units. copper core
3 sets of 16A five holes universal socket and 1 air conditioning socket
Electrical distribution box + breakers + earth leakage protective device
Others Lift corner piece . Rainspout: Φ50PVC pipe and others
Optional1.Exhaust fan
2. Floor heating: 100mm thickness fiber glass(16kg/m3), Fire-proof level: A
3. Sanitary ware:
Western Close tool: ceramic, with pipes and installation fittings
Urinal: ceramic, with pipes and installation fittings
Wash basin: ceramic, with post, faucet, pipes and installation fittings
Shower head, Shower base, Water mixture

4. Air condition
5. Office furniture
Packing6sets in a 40GP/40HQ container
Modern Design Luxury Living 3 Bedroom Container House with Toilet


The main features for container house:
1) It could be widely used as house, office,meeting room,dormitory, storage, shower rooms,guard, toilet,hotel, shop, restaurant, booth, kiosk etc.
2) Several units could be combined and stacked to be a big beautiful building based on customized designs, with inside,outside, stairs, aisles and porch container house.
3)It could be assembled and disassembled by hands, 100% nut-bolt connection, two men could install one set in 2hours.
4)The top and bottom main steel frames were welded separately, upgrade and strengthened panels, door, window, it is of high firmness and excellent performance of waterproof, thermal and sound insulation with long service.
Modern Design Luxury Living 3 Bedroom Container House with Toilet
The features of  sandwich and frame
1) Light weight.

2 )Strong fire and corrosion resistance.
3) Heat absorption and sound insulation.
Modern Design Luxury Living 3 Bedroom Container House with Toilet
Frame: Q235 Strip Steel
Hot rolled galvanized, anti-corrosive coating,
Thickness: 2.5/2.7/3.0 mm
Corner post: Galvanized, anti-corrosive2.5/ 3.0mm

Connection: high-strength bolt M12*40


Modern Design Luxury Living 3 Bedroom Container House with Toilet

Detailed Dates for Specifications (Standard container house)
1Live load capacity of roofing0.6kn/m2
2Second Floor Load Capacity150 kg/m2
3Live load of corridor2.0kn/ m2
4Wall permitted loading0.6KN/ m2
5Ceiling Permitted live loading0.5 KN/m2
6Wall Coefficient of thermal conductivityK=0.442W/m2k
7Ceiling Coefficient of thermal conductivityK=0.55W/ m2K
8External and internal wall heat transmission coefficient0.35Kcal/m2hc
9Wind resistanceGrade 11 (wind speed≤ 120km/h)
10Earthquake resistanceGrade 10
Modern Design Luxury Living 3 Bedroom Container House with Toilet
Modern Design Luxury Living 3 Bedroom Container House with Toilet


Modern Design Luxury Living 3 Bedroom Container House with Toilet
Modern Design Luxury Living 3 Bedroom Container House with Toilet
